RAVENOL GHA-F Gearbox Hydraulic Actuator Transmission Fluid is a special hydraulic fluid based on synthetic and mineral oils blended with non-ash forming additives. It was developed for use as a special hydraulic fluid in electro-hydraulic gearboxes and electrically controlled gears and gearshifts.
Application
RAVENOL GHA-F Transmission Fluid was designed for use in electrically controlled MCP automatic transmissions from Peugeot/ Citroen and in Dualogic and Selespeed automatic transmission from Fiat/ Alfa Romeo. It is suitable for use in temperatures ranging from -40°C to +100°C.
Meets/ Exceeds Requirements
- Peugeot/ Citroen 9979.A4 for MCP Automated Gearbox
- FIAT 14621616
- FIAT 9.55550-SA1
- FIAT Nr.F005.F98
- FIAT / Alfa Romeo 15081616 CS SPEED for Dualogic
- Suzuki 99000M24121-135
- Suzuki Actuator Fluid
- Vauxhall / Opel 93165151
RAVENOL GHA-F Transmission Fluid offers:
- Extremely low pour point.
- Improved viscosity and friction value characteristics.
- Very good wear protection.
- An excellent thermal stability.
- Improved EP properties.
- Good foaming characteristics.
- Neutral behaviour towards sealing compounds.
- Reliable protection against corrosion.
Technical Product Data
| Property | Unit | Data | Audit |
| Density at 20 °C | kg/m³ | 827,0 | EN ISO 12185 |
| Colour | | grün | VISUELL |
| Viscosity at 100 °C | mm²/s | 6,6 | DIN 51562-1 |
| Viscosity at 40 °C | mm²/s | 19,7 | DIN 51562-1 |
| Viscosity Index VI | | 333 | DIN ISO 2909 |
| Pourpoint | °C | -54 | DIN ISO 3016 |
| Flashpoint | °C | 164 | DIN EN ISO 2592 |
All indicated data are approximate values and are subject to the commercial fluctuations.
Please note that the technical data is correct at the time of writing, Ravenol are continuously updating product specifications. Therefore, please refer to the 'Download PDF' and 'Safety Data sheet' links above for up-to-date information.
12 April 2024 | Gary
Amazing price compared to main dealer price of £90. Fast delivery and a pleasure to deal with.
Was this helpful to you? Yes / No
11 August 2022 | Ashley
Replaces OEM actuator oil in Alfa TCT gearbox (only done 30k) and changes feel a lot smoother, especially when cold. Specs show it's a better oil than the factory fill, shame it's semi synthetic and not fully synthetic. But was the only oil outside OEM that had the Alfa / Fiat accreditation.
Was this helpful to you? Yes / No
15 September 2021 | Ray
Ravenol was recomended to me as the fluid I purchased is a specialist item not stocked in general motoring stores and the dealer price was quite high compared to Ravenol. Enabled me to get my car functional quickly and from ordering to online to delivery was smooth and fast. I would have no hesitation in using your company for further purchases a definate thumbs up from me thank you !
1 of 1 people found this review helpful.
Was this helpful to you? Yes / No
Response:
Glad we could help Ray.
20 April 2021 | Phillip
Excellent and a very competitive price
Was this helpful to you? Yes / No
Good product fast delivery. 07 October 2020 | Bill
For Fiat Control Actustor. Correct specification.
Was this helpful to you? Yes / No
25 February 2019 | Neil
Nice oil, used this in my Alfa automatic. Wouldn't switch back, she's doing great
3 of 3 people found this review helpful.
Was this helpful to you? Yes / No
Read all 7 customer reviews...
